Hangzhou Freqcontrol Electronic Technology Ltd. We Grow Crystal. We Fabricate Wafer. We are Piezoelectric Specialist.
4 Years
| Ask Lasest Price | |
| Brand Name : | BonTek |
| Model Number : | Single Crystal Quartz |
| Certification : | ISO:9001 |
| Price : | Negotiable |
| Payment Terms : | T/T, Western Union |
| Supply Ability : | 100000 pieces/Month |
| Delivery Time : | 1-4 weeks |
Single crystal quartz wafers/blanks are made of synthetic quartz crystal. It has good piezoelectric effect and is widely used in timing frequency control, frequency selection and QMEMS. Cutting-edge applications include VCXO, TCXO, OCXO
Material Characteristics
| Material | Piezo / Optical grade |
| Q-Value | Min 1.8x10^6, 2.4x10^6 to 3.0x10^6 IEC standards |
| ECD | Max 2 /cm², 10/cm², Max 30/cm², Max 100/cm², Max 300/cm²; Swept Quartz |
| Inclusions Density | Ia, Ib, I, II, III Grades |
| Swept | Both Pure Z and Y Bar available,with or without Swept quartz |
processing capacity - blanks
| Cuts Type (orientation) | X, Y, Z, AT, BT, CT, ET ,DT, GT, NT, FC, SC, IT, AC, BC, ST, TS MT ,NT RT, LC…, etc |
| Angle Tolerance(±) | Theta Angle: ±5″, ±10″, ±15″, ±30″, ±1′, ±2′, …, etc. |
| Phi Angle: ±5′, ±10′, ±15′, ±30′, …, etc. | |
| Size | Round (3.0mm~8”)/ Square (1.6x1.6mm~48x48mm or larger)/ SMD (1.2x2.4mm Above) |
| Size Tolerance(±) | ±0.01mm,+/-0.005mm, +/-0.0005mm, according to size |
| Frequency/ Thickness | 1 Mhz up to 54Mhz for AT-Cut Fundamental ; Up to 70Mhz by Etching |
| Flat | Per requested: the flat shall be perpendicular to X axis within ±10 deg |
| Surface Finishing | #1000(9u); #2000(7u); #3000(5u); #4000(3u) (Sic); Polished(Cerium oxide)& etched Std |
| Overtone | Fundamental ; Third Overtone (3rd); Fifth Overtone (5th) |
| Contouring (dioptric) | Plano-Convex : 0.5 dioptric~10 dioptric Bi-Convex : 10 dioptric~15 dioptric |
processing capacity - wafers
| Diameter | 3”(76.2mm) | 4”(100mm) | 6”(150mm) | 8”(200mm) |
| Thickness | 0.08mm Min-up | 0.10mm Min-up | 0.20mm Min -up | 0.35mm Min- |
| Primary Flat | 22mm | 32mm | 42.5mm | 57.5mm or notch |
| Surface | LTV (5mmx5mm) | <1.5µm | TTV | <1.5~3 µm |
| Bow | -30<bow<30 | Warp | <40µm | |
| Surface Type | SSP / DSP | Edge Criteria | R=0.2mm or Bullnose | |
| Polished side Ra | <0.5nm or per requested | Back Side Criteria | General is 0.2-0.5µm or as customized |
FAQs:
A: We look at ourselves as the piezo wafer specialist. We are the very first to work with Single Crystal Quartz in China about 30 years ago. Then gradually we step in the field of LiNbO3, LiTaO3, Quartz glass, LGS, CTGS etc. Especially, if you are looking for a piezo quartz supplier, we are the ultimate choice! We export millions of quartz blanks each year because we master the AT, SC and IT cuts with superior angle precision.
A: Yes, of course. We can fabricate as per your request. In addition, we are so experienced with piezo wafers that we can provide you relevant suggestions if you are not 100% sure about your choice. Besides, we do have some standard wafers in stock, please check with us.
A: Yes, we would suggest you go with the courier agent you are most familiar with (DHL, FedEX, UPS etc.). We can ship via your account. And, of course, we will pack the products safely in acceptable size to help you save the shipping cost. If you need us to take care of the freight, it’s also not a problem. We also have good discount with the international courier companies.
A: The wafer products are fragile and sometimes expensive. The last thing, as the manufacturer, we want to see is the products we make were damaged during courier. As a result, we will pack the wafers adequately and put them in a proper carton filled with buffer sponge. However, accidents are inevitable sometimes. So, please follow the “Acceptance check” steps shown in the drawings below. If the unwanted happened, we will either give the replenishment or refund if you follow the checking steps.
A: Sure. Factory inspection is important for large quantity purchase and long-term cooperation. Face to face discussion is what we mostly confident with. During the past years, big names around the world have witnessed our progress in factory build-up. These days, due to the Covid-19 pandemic, we also had the experience of videoconferencing with global buyers.
Acceptance Check
1. The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.
2. After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.
3. Please open the vacuum package in a clean room when the products are to be applied.
4. If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
|
|
